SY-B035 Medical Analyser Auto glycated hemoglobin HbA1c Analyzer machine
Brand Name: Sunnymed
Model Number: SY-B035
Packaging Details: Carton or wooden case, standard export packing
Delivery Detail: In 10 days after payment received
Port: Guangzhou
Description
Feature:
Easy Operation
High-definition color touch screen, touch-tone menu, operation freely
4.5 minutes per sample
1-15 samples, Cal 1, Cal 2, QC, ST
5-20ul whole blood, put into sample cup, press ” START”
Expand Capacity
Remote monitoring, online upgrade, Interface to LIS system
Independent TF card, user can copy the sample data to PC easily,
and print comprehensive report for each patient.
Simple Maintenance
Full Modular Design
Automatic washing channel
Easy to change the chromatography column
Performance Characteristics
| Within-Run (n=20) | Inter-Run (n=20) | |||
| Sample | Low | High | Low | High |
| Mean(%) | 5.58 | 10.24 | 5.84 | 10.18 |
| SD | 0.08 | 0.09 | 0.12 | 0.15 |
| CV(%) | 1.43 | 0.87 | 2.13 | 1.47 |
Testing Method Low pressure ion exchange liquid chromatography
Testing Item Glycated hemoglobin HbA1c
Testing Time 3 minutes (reporting),
Full-processing 4.5 minutes (including cleaning column and recovery time)
Testing Parameters Precision (CV) ≤ 3%, Accuracy(V) ≤1.50%
Testing Scope 3.0%-18.0%
Sample Type Whole blood, dilute blood
Sample Volume 5-10ul
Photometer 415nm LED Integral flow colorimeter
Calibration Optional selection of 2 points calibration, optional selection automation, Equipped
with 2 groups of high and low level calibrators
Reagent allocation Each standard package includes A, B, C, D eluent, calibrator,
and hemolytic agent, pump tubing
Display 320×240 LC Graphic display, displaying real-time testing curve
Printer 58nm Thermal printer, printing testing curve and report
Panel 0-9, YES, NO, START, STOP, ST, PRINT
Data Storage 2G TF Card, 100,000 test reports (including Curve)
USB port Support remote upgrading, LIS interface
PS-2 port External Barcode Scanner
Power Supply AC220V±22V, 50Hz±1Hz
Working Environment Temperature 10-30°C, Relative humidity 30%-75%
Size 550 mmx405 mmx347mm
Weight 12kg
