Description

Features

1 Infrared optical detection technology

2 Automatically scanning blood cells and location of the plasma interface from time to time with accurate positioning

3 Internal thermal printer, ESR curve display and print-out

4 Automatically amending the ESR results under the detecting temperature (15°C ~32°C)to the ESR values at

18°C, closely related with Westergren results

5 The results are not interfered by high levels of hemoglobin, bilirubin or triglyceride

Technical Parameters
Measuring principle            Infrared barrier
Measuring time                30 minutes
Measuring precision            <0.2 mm
Reproducibility                < 3%
Temperature Precision                  <0.3°C
Sample volumn                             <1.6mL whole blood anticoagulant
Reading channel                          10
Display                                      LCD screen with backlight
Interface                       RS-232 serial port
Print                          Internal thermal recorder
Operation conditions                          Temperature  15C°~32°C
Humidity  ≤85%
Power supply                    AC 220V/110V ±10%, 50/60 Hz
Dimension                                    320mm×260mm×158mm (L×W×H)
Net weight                                        5.0 kg
