Designed to be more appealing for everyday use, and feel less like a medical device.
The top handle makes it more easy to carry.
And the trolley is another portable way that we can use in home and go outside,
this way saves us much time and effort.
| Continuous Flow Settings | 0 – 5 LPM, LPM= Liter Per Minute |
| Oxygen Concentrations | 93% +/- 3% at 1 LPM
60% +/- 3% at 3 LPM 40% +/- 3% at 5 LPM |
| Outlet Pressure | 8.5 PSI |
| Sound Level | ≤ 43 dB (nominal) at any setting |
| Size | 10.2 in x 7.7 in x 15.2 in(26 cm x 19.5 cm x 38.7 cm) |
| Weight | 12 lbs (5.4 kg) without battery |
| User Interface | Push buttons, back-lit liquid crystal display (LCD) |
| Filtration | air inlet filter, bacteria filter |
| Operational Temperature | 41° to 104°F (5° to 40°C) |
| Relative Humidity | 15 to 95% |
| Altitude | Up to 12,000 ft (3657 m) |
| Storage Temperature | -4° to 140°F (-20° to 60°C) unit only |
| Relative Storage Humidity | Up to 95%, non condensing |
| Power Consumption | 90W |
| AC Power Input | 100 to 240 VAC, 50/60 Hz, 1.8 A max |
| AC Power Output | 14.8 VDC, 8 A max |
| DC Power Input | Input 11. to 16.8 VDC 20 A max |
| DC Power Output | 14.8 VDC, 8 A max |
| Audible Alarm Sound Level | 55 dB (nominal) at 39 in (1 m) |
| Alarm type | No power , No flow, Low battery, Depleted battery,
Wrong battery, System technical fault |
| Chemistry of Battery | Lithium Ion 14.8 VDC (nominal) |
| Battery Dimensions | 6.1 in x 3.4 in x 2 in(15.5 cm x 8.5 cm x 5 cm) |
| Battery Weight | 1.5 lbs (0.7 kg) |
| Battery Charge Time | Approximately 4 to 5 hours |
| Battery Duration | 59-61 minutes at 0-5 LPM continuous flow setting |
