SY-P019 Video Laryngoscope Electronic Digital Camera Portable Laryngoscope

Brand Name: Sunnymed

Model Number: SY-P019

Packaging Details: Carton or wooden case, standard export packing

Delivery Detail: In 10 days after payment received

Port: Guangzhou

Endoscope, Video endoscope

The portable multifunctional video laryngoscope, is new video intubation system

which can expose laryngeal structure more directly and distinctly, reduce damage

and difficulty caused by tracheal intubation. It is suitable for preoperative intubation

of anesthetist because of the great help to difficult tracheal intubation,

especially tracheal intubation during emergent treatment of

non-anesthetist in ICU and emergency room.

Combining high-definition digital imaging system

and unprecedented ergonomic design, it can easily evaluate anatomical structure

and fast locate tracheal tube by its high-resolution color real-time image.

It helps to enhance success rate of your operation and greatly ease pains of patient.

Model	SY-P019
Imaging mode	Full digital color imaging
Imaging module	Dimension	1/12inches
	Effective pixels	NTSC 720(H)525(V) PAL: 729(H)625(V)
	Minimum illumination	0.8Lux
	SNR	38 DB
	Dynamic range	66 DB
	Aperture	F2.8
	Focus	20mm-70mm
	Viewing angle	90°(LCDdiagonal)
Display system	Monitor dimension	2.4″TFT-LCD
	Monitor rotation angle	0°~120°
	Backlight mode	2 LED lamps in series
	Resolution	640(H)×240(V)
	Visual range	U/D/L/R(20/50/40/40)
	Illumination	>250cd/m²
	Display dimension of LCD monitor	44.46(H)×61.7(V)
	Visible area	37.8(H)×50.279(V)
	Output	PAL/NTSC Composite video signal
Illumination	Light source	White LED
Power supply	Voltage	3 AAAalkaline batteries
	Power consumption	2W
	Average service life of battery	45 minutes (alkaline battery)
Memory capacity	128MB
External dimension(B x H x T)	51x330x75.5mm
